4.5 TOPCASE
Releasing and removing the topcase.
Fig. 29
For opening insert the red key inside the lock and turn it to the right through 90°.
The closing takes place in the inverse order.
To release the topcase, also open the lock with the red key and afterwards press button A.
Now the topcase ce be released. C = grap handle.
Do not load the topcase with more than 15 kg!
32
