3.9 BELT TENSION
1. For adjusting the belt tension the Allen screws 1, 2 and 3 must be unscrewed.
(tighten turnbuckles steady).
2. Now it should be possible to push the belt approx. 5 mm downwards.
3.
1 2 turns.
4. Make a test drive and check the screws and the tension of the belt once more.
Fig. 18
Fig. 19
