BOOM TRIKES V2 Automatic - Page 53

V2 Automatic Recommended torque settings
Lubrication
Vehicle component
Torque setting (Nm)
Engine oil drain plug
21 29
Screws divider oil pump
3 4
Chain tensioner rest oil pump chain
12 16
Screw oil pump
5 6
Bloy-By line fixing screw
11 13
Upper divider lubricant circuit
3 4
Screw drive sprocket oil pump
10 14
Fixing screw oil pump at housing
5 6
Oil pressure sensor
10
Fixing screw cogwheel water pump
5 6
Thermal unit and valve control
Vehicle component
Torque setting (Nm)
Spark plug
12 14
Setscrew cylinder head fixture
***
Cylinder head nut
10 12
Fixing screws cylinder head inlet/outlet
10 12
Controlling nozzle lubrication cylinder head
5 7
Fixing screw guide shoe, chain tension shoe
10 14
Fixing screw injection nozzle
3 4
Fixing screw intake manifold
11 13
Fixing screw tappet covering
7 9
Fixing screw throttle body
11 13
Fixing screw camshaft holder
4 6
Fixing screw cylinder head
10 12
Coolant temperature sensor
21 23
Fixing screw speed phase sensor
7,5 8,5
Screw chain tensioner valve control
11 13
Screw sprocket valve control at camshaft
12 14
*** First time tighten crosswise with 10 Nm  then tighten crosswise with a torque of 13 Nm +90°  once again tighten crosswise with 90°.
Drive lid
Vehicle component
Torque setting (Nm)
Nut drive pulley
252 278
Nut conducted pulley
252 278
Clutch threaded ring
65 75
Screws outer drive cover
5 7
Screws innter drive cover
11 13
Screws bargeboard
3 4
Screws grill air outlet
3 4
Alternator lid
Vehicle component
Torque setting (Nm)
Fixing screw flywheel
116 128
Fixing stator
8 10
Fixing screws freewheel
13 15
Screws alternator
11 13
