INGENIO COMPACT 10-20kVA Руководство по быстрому монтажу
Installation and start-up of INGENIO COMPACT 10÷20 kVA
OMS90052 РЕД. / REV.A 31
 Rear side of front door view
1.
USB Port for Setting Software
4.
Output & Input Contacts
2.
SD Card Slot
5.
RS-232 Port for Setting
Software
3.
External Battery Temperature
Connector
6.
Communication Port for Remote
Panel
4.
5.
6.
