All menu functions are showing in below table.
Menu Sub-Menu Functions
Mimic Display
Display the UPS status、alarm、operating mode
and measurements. Please refer to section 4-3 for
more detail.
Command
#1
Operation
 Normal mode
 ECO mode
 Converter mode
 Shutdown
 Shut down converter except bypass
 Cold start precharge ready
Buzzer &
Alarm
 Enable/Disable Buzzer
 Clear latch alarm and buzzer.
Other

Recover backfeed protection signal
 Battery Test
Monitor
Identification Display UPS information
Real Time
Information
Display real time measurements of input, output,
bypass and battery.
Maintenance
Code
Display the maintenance code for technician to
check the status of the UPS.
Version
Disply the control MCU software and firmware
version.
Configuration
Alarm
Set alarm latch function.
 General Alarm
 Mains Alarm
 Bypass Alarm
 Over Temperature
 Battery Low
 Inverter Overload
 Bypass Overload
 Emergency Stop
Main
Select the measurements on Mimic Display.
Bypass
Output
Menu Sub-Menu Functions
Management
Schedule Display the schedule.
Schedule
Setting
#1
To define the schedule for ECO mode.
