Pagina 15 di 36 OMP68017 Rev. D 24/12/17
STS SUPPLY
As soon as a source is connected, the STS will turn on automatically. The LCD will turn on
as shown in the left figure and the LEDs will light up.
After the start-up, the display is as shown in the right figure, and the LEDs for Sources A
and B light up.
SWITCH BETWEEN SOURCE A SOURCE B
The ATS supports manual control for switching between source A source B.
Press the button for 2 seconds until you hear 2 consecutive “beeps”.
The system requires confirmation of the switching of the supply (LCD will show on the LCD
as shown in Figure 1), to confirm, press the button again for 2 seconds, the LCD
display will display the new source that powers the output (Figure 2). If the output is not
available, the display will display an alarm and the switch of supply will not occur.
Figure 1 Figure 2 Figure 3
