Borri STS-16 User Manual

Pagina 17 di 36 OMP68017 Rev. D 24/12/17
TECHNICAL SPECIFICATIONS
TYPE/MODEL
STS - 16
STS - 32
INCOME PARAMETERS
Mains voltage
200V / 208V / 220V / 230V / 240V
(can be set via software: +/- 5%, 10%, 15%, 20%)
Voltage range 150Vac~300Vac
Input frequency
50/60 Hz (can be set via software: +/- 5%, 10%, 15%,
20%)
Input current. 16 A 32 A
OUTPUT PARAMETERS
Output voltage 200V / 208V / 220V / 230V / 240V
Output Current 16 A 32 A
Overload
101-110% Pre-alarm
110-125% 1min.
125-150% x 30sec.
150-200% 5 sec.
> 200% x 1 sec.
101-110% Pre-alarm
110-125% 1min.
125-150% x 30sec.
150-200% 5 sec.
> 200% x 1 sec.
CONNECTIONS
Input Connections IEC-C20 x2 Terminals for 40 A x 6
Output Connections
IEC-C13 x 8,
IEC-C19 x 1
IEC-C13 x16,
IEC-C19 x2
Protections
Input Switch (Optional)
Electronic protection system
Communication
RS-232, USB, clean contacts,
Optional card Slot (SNMP, RS-485)
Switching time in phase
(ms)
2 – 6 ms
Efficiency 98.2% (at full load)
Display LCD + LED
DIMENSIONS:
W x L x H (mm) 275 x 440 x 88 275 x 440 x 88
Weight (Kg) 6 6
ENVIRONMENTAL PARAMETERS
Operating temperature -5 ÷ +40 °C @ 20~90% RH
