Bosch Active Series User Manual

English – 15
(10)
(11)
(12)
(13)
(14)
(17)
(16)
(15)
Product Features
All illustrations of bike parts except for the drive unit, on-board computer in-
cluding operating unit, speed sensor and the corresponding holders are
schematic and may differ on your eBike.
(1)
Bike light button
(2)
Protective cap for USB port
(3)
On/off button for on-board computer
(4)
Holder for on-board computer
A)
(5)
On-board computer
(6)
Display (touch-sensitive)
(7)
Brightness sensor
(8)
USB port
(9)
Release mechanism
(10)
Button for next page
(11)
Select button
(12)
Button for decreasing the assistance level
(13)
Holder for operating unit
