Conettix Cellular Communicators Component overview | en 5
Bosch Security Systems, Inc. Installation Manual 2018.04 | 02 | F.01U.345.070
2 Component overview
Cellular plug-in communicators provide IP communications over supported cellular networks
by directly connecting the communicator into a control panel or into an additional module
such as the Conettix Plug-in Communicator Interface or the Conettix Universal Dual Path
Communicator modules. Some communicators come with a SIM card holder.
Communicators without SIM cards
Callout - Description
1 - Module handle and support leg
2 - LEDs
3 - Threaded female SMA antenna connector
4 - Plug-in module retention clip opening
5 - PCB metal contacts
Notice!
The B440-C/B441-C communicators must be activated and have a valid cellular plan for
proper usage. Refer to Activating the B440-C/B441-C, page 12 for details.
