Bosch B4512 User Manual

Control Panels B94x Keypad operation overview | en
31
Bosch Security Systems B.V. 2019.06 | 07 | F.01U.307.371
11.1.1 Idle screen
When the main display area shows the idle screen, it uses words,
numbers, and symbols to show the status of the security system. When
several events occur, the keypad shows each event in order of priority.
The Main icon serves as both an indicator of the arming state and
alarms, and as an icon to press to change the arming state. The text
above the icon provides instructions.
Ready to arm. Indicates that the system is ready to turn on
(arm). Press the icon to turn on (arm) the security system.
Not ready to arm. Indicates that the system is not ready to turn
on (arm). Press the desired icon to resolve the faults.

Bosch B4512 Specifications

General

Control Panel Type	Hybrid
Wired Zones	8
Outputs	2
Programmable Outputs	2
Onboard Ethernet	Yes
Cellular Communication	Optional
Series	B Series
Partitions	2
Type	Control Panel
Model	B4512
Manufacturer	Bosch
Input Voltage	16.5 VAC
Communication Formats	Contact ID, SIA
Power Supply	16.5 VAC
Backup Battery	12 V, 7 Ah
Operating Temperature	0°C to +50°C
Weight	1.5 kg
Compatibility	Bosch accessories
