Control Panels Keypad Installer menu | en 157
Bosch Security Systems, Inc. Installation and System Reference Guide 2016.06 | 08 | F.01U.303.996
Signal Strength (for RF points)
B91x/B92x keypads use of Signal Strength (for RF points)
1. Enter the installer passcode, and then open the [1] Installer menu.
2. Go to [2] Wireless > [3] RF Diagnostic Menu > [1] RF Point Menu> [1] Strength.
3. Use [PREV] or [NEXT] to scroll though the list, and go to the point for which you want to
view diagnostic information, or enter the point number.
4. Press [ENTER] to view the signal strength. The menu scrolls through the following sub-
categories, with the results of the diagnostic check: Signal Strengths, Level, Margin.
5. When finished viewing the information, escape from the menu.
B93x/B94x keypads use of Signal Strength (for RF points)
1. Enter the installer passcode, and then open the [1] Installer menu.
2. Go to [2] Wireless > [3] RF Diagnostic Menu > [1] RF Point Menu> [1] Strength.
3. Use /[PREV] or /[NEXT] to scroll though the list, and go to the point for which you
want to view diagnostic information, or enter the point number and press [ENTER].
4. Press [Signal] to view the signal strength. The menu scrolls through the following sub-
categories, with the results of the diagnostic check: Signal Strengths, Level, Margin.
5. When finished viewing the information, escape from the menu.
20.2.8 [3] RF Diagnostic Menu > [2] RF Repeater Menu
You can obtain certain wireless point diagnostic information using a keypad and this menu.
States (for RF repeaters)
B91x/B92x keypads use of States (for RF repeaters)
1. Enter the installer passcode, and then open the [1] Installer menu.
2. Go to [2] Wireless > [3] RF Diagnostic Menu > [2] RF Repeater Menu > [1] State.
3. Use [PREV] or [NEXT] to scroll though the list, and go to the repeater for which you want
to view diagnostic information, or enter the repeater number.
4. Press [ENTER] to view the state. The menu scrolls through the following sub-categories,
with the results of the diagnostic check: State, Missing, Tamper, Low-Battery, Low-
Battery.
5. When finished viewing the information, escape from the menu.
B93x/B94x keypads use of States (for RF repeaters)
1. Enter the installer passcode, and then open the [1] Installer menu.
2. Go to [2] Wireless > [3] RF Diagnostic Menu > [2] RF Repeater Menu > [1] State.
3. Use /[PREV] or /[NEXT] to scroll though the list, and go to the repeater for which
you want to view diagnostic information, or enter the repeater number and press
[ENTER].
4. Press [State] to view the state. The menu scrolls through the following sub-categories,
with the results of the diagnostic check: State, Missing, Tamper, Low-Battery, Low-
Battery.
5. When finished viewing the information, escape from the menu.
Signal Strength (for RF repeaters)
