7 ADVANCED MENU
MAIN MENU
This enhanced software makes programming and
customizing your BasicDome easy. All settings can be
edited using the Main Menu. To enter the Main Menu,
press ON-46-ENTER. You then simply follow the
on-screen commands to edit the settings. Remember,
to access this feature, the system must be unlocked
using OFF-90-ENTER.
CAMERA SETUP
White Balance – A camera function that maintains proper color reproduction as the color temperature of the scene changes
(i.e. daylight, flourescent). The Factory Default* setting is AUTOMATIC.
Choices:
Extended WB . . . . . .Camera adjusts color using extended range.
*Automatic WB . . . . .Camera constantly adjusts the color.
Indoor WB . . . . . . . . .Camera optimizes color for typical indoor conditions.
Outdoor WB . . . . . . .Camera optimizes color for typical outdoor conditions.
One Push WB . . . . . .Sets the camera’s color settings for the current scene. Zoom on a well lit, white object
(i.e. a white wall or paper) before activating.
Gain Control – Electronically brightens darker scenes which may cause graininess in low light scenes. The Factory Default*
setting is AUTO.
Choices:
Off . . . . . . . . . . . . . . . .Camera uses only the IRIS to adjust to low light.
*Auto . . . . . . . . . . . . . .Camera adds electronic gain based on lighting conditions.
Max Gain Level – Adjusts the maximum gain level that the Gain control will adjust to when set to AUTO.
Choices: . . . . . . . . . . . . . .Sliding Scale from 1 to 6 (in 4 decibel gain steps).
Sharpness – Adjusts the sharpness/detail of the picture. The Factory Default* setting is at 6 on the sliding scale of about 16.
Choices: . . . . . . . . . . . . . .Sliding Scale from –(soft) to +(sharp).
Synch Mode – Sets the synch mode of the camera. The Factory Default* setting is LINE LOCK.
Choices:
Crystal . . . . . . . . . . . .Camera is synchronized to an internal crystal (recommended if there is noise on the power line)
*Line Lock . . . . . . . . .Camera is synchronized to AC power. This eliminates picture roll in multicamera systems.
Line Lock Delay – Optimizes LINE LOCK mode to eliminate picture roll in multiphase power applications. The Factory
Default* setting is 0.
Choices: . . . . . . . . . . . . . .Sliding Scale (–0° to 359°).
Backlight Compensation – Improves the image quality when the background has a high level of illumination.
Choices: . . . . . . . . . . . . . .On, Off.
