4 | BAT 131 | Symbols useden
Contents
1. Symbols used 4
1.1 In the documentation 4
1.1.1 Warning notices - Structure and
meaning 4
1.1.2 Symbols in this documentation 4
1.2 On the product 4
2. User information 5
2.1 Important notes 5
2.2 Safety instructions 5
2.3 Intended use 5
3. User Interface 5
3.1 Scope of delivery 5
3.2 Product description 5
3.3 Function of the keys 5
3.4 Switch on 5
3.5 Switch off 5
3.6 Menu 6
3.7 Special accessory 6
4. Perform Test 6
4.1 Test Preparations 6
4.2 Connecting BAT 131 6
4.3 Battery Test 6
4.4 Battery Test Results 7
4.5 Starter System Test 8
4.6 Starter System Test Results 8
4.7 Charging System Test 8
4.8 Charging System Test Results 9
4.9 Additional Test Messages 9
5. Unused Battery Mode 10
6. Maintenance & Troubleshooting 11
6.1 Cleaning 11
6.2 Service Parts / Parts Subject to Wear 11
6.3 Changing the Printer Paper 11
6.4 Changing The Cable Assembly 12
6.5 Replacing the Battery 12
6.6 Troubleshooting the Display 13
6.7 Troubleshooting the Printer 13
6.8 Disposal 13
7. Technical data 13
7.1 Battery-Test and Voltmeter 13
7.2 Printer Paper 13
1. Symbols used
1.1 In the documentation
1.1.1 Warning notices - Structure and meaning
Warning notices indicate hazards and their consequen-
ces for the user or surrounding persons. Warning noti-
ces also describe the measures for preventing these
hazards. The signal word has a crucial importance. It
indicates the probability of occurrence and the severity
of the hazard in case of non-compliance:
Signal
word
Probability of
occurrence
Severity of danger if in-
structions not observed
DANGER Immediate impend-
ing danger
Death or severe injury
WARNING Possible impending
danger
Death or severe injury
CAUTION Possible dangerous
situation
Minor injury
Below you will see an example of the “Live parts”
warning notice by way of example, with the signal word
DANGER:
DANGER – Exposure of live parts on ope-
ning the BAT 131!
Risk of (fatal) injury or heart failure from elec-
tric shocks on contact with live components.
¶ Work on electrical installations or equip-
ment is only to be performed by qualified
electricians or trained personnel under the
guidance and supervision of an electrician.
¶ Disconnect BAT 131 from the mains before
opening.
1.1.2 Symbols in this documentation
Sym-
bol
Designation Explanation
!
Attention Warns about possible property damage.
i
Information Practical hints and other
useful information.
1.
2.
Multi-step
operation
Instruction consisting of several steps
e
One-step
operation
Instruction consisting of one step.
Intermediate
result
An instruction produces a visible inter-
mediate result.
"
Final result There is a visible final result on comple-
tion of the instruction.
1.2 On the product
! Observe all warning notices on products and ensure
they remain legible!
