Operating Instructions
|
BAT 155 Battery Tester | 3
|
en
BAT 155 | REV. A | October 2020
Arrow Keys
Display Screen
(Home Screen)
Cover Lifter
Printer
Enter Key
Amp Clamp Jack
Voltmeter Jack
USB Port
SYSTEM ANALYZER
1 Introduction
The BAT 155 Battery Tester is used to test 6 and 12 volt batteries, and to test
12 and 24 volt charging systems. (ONLY 12 volt for battery pack testing) The
suggested operation range is from 0 degrees Centigrade (32 degrees Fahrenheit)
to 50 degrees Centigrade (122 degrees Fahrenheit) in ambient temperature.
