Bosch BC3200RA - General Parts; Main Unit

99
Operating Instructions
General Parts
Main Unit
·
The above illustration shows an example of installation.
The exact installation configuration may be slightly different.
Front Cover
Exhaust vent pipe
Water Drain Valve
(with Water Filter)
(Inside Water Inlet)
( P31)
Water Supply Valve
Air inlet
Gas Supply Valve
Lit during combustion.
Blinks to indicate a problem.
( P35)
Burner On Indicator
Drain Pipe
Discharges the condensate.
