-19-
Description fonctionnelle et spécifications
Débranchez la fiche de la prise de courant avant d'effectuer quelque assemblage
ou réglage que ce soit ou de changer les accessoires. Ces mesures de sécurité
préventive réduisent le risque d'une mise en marche accidentelle de l'outil.
A
VERTISSEMENT
!
Scie circulaire
REMARQUE : Pour spécifications de l'outil,
reportez-vous à la plaque signalétique de
votre outil.
Capacités maximales
Numéro modèle
CS5
Lame 184 mm
Moyeu de lame
rond 5/8"
Profondeur de coupe à 90° 62 mm
Profondeur de coupe à 45° 46 mm
LEVIER DE LEVAGE DU
GARDE INFÉRIEUR
GARDE INFÉRIEUR
ÉCHELLE DES
ANGLES DE BISEAU
SEMELLE
POIGNÉE
AUXILIAIRE
GARDE SUPÉRIEUR
LEVIER DE VERROUILLAGE
GÂCHETTE
FIG. 1
PRISES D'AIR
CLÉ ET CASE DE
REMISAGE
LEVIER DE RÉGLAGE DE
LA PROFONDEUR
LEVIER DE
RÉGLAGE DU
BISEAU
SECTEUR GRADUÉ
SUPPORT À
PROFONDEUR
GRADUÉE
