Bosch D7212G - POPIT Module Point Assignments; Program Record Sheet; Figure 14: Program Record Sheet

D7212G Operation and Installation Guide
D7212G
Page 41© 2003 Bosch Security Systems 4998138544C
Off-board Points
8.3.6 POPIT Module Point Assignments
Seven switches on each D9127U/T POPIT (six on each D8127U/T POPIT) assign the module to a point number. POPIT
switch settings are found in Point Assignment in the D7212G Program Record Sheet (P/N: 4998138542). See Figure 14.
8.3.7 Program Record Sheet
The eight columns on the D7212G Program Record Sheet (P/N: 4998138542) contain the following information:
•
First column (POPIT Switch Settings): the switch settings for the D8127 POPITs. Switches are numbered 1 to 6,
left to right on the D8127 POPIT. Switches are numbered 0 to 6, left to right on the D9127 POPIT. Set switches
with numbers that appear in the setting to the ON position. Set switches with a dash (-) in the switch position to
the OFF position. See Figure 14.
•
Second column (Translation): the translation of the point number into the ZONEX format. See Point User Flag
in the D7212G Program Entry Guide (P/N: 4998138538) for an explanation of this feature.
•
Third column (Point #): the point number as it is displayed at command centers.
•
Fourth column (Point Index): See Point Index Parameters in the D7212G Program Entry Guide (P/N: 4998138538)
for an explanation of the point index.
•
Fifth column (Area Assign): the area the point is assigned to.
•
Sixth column (Debounce): the Debounce Count for the point. See Debounce Count in the D7212G Program Entry
Guide (P/N: 4998138538).
•
Seventh column (BFSK/Relay Entry): the BFSK/Relay report code. It is the point number reported for this point
when the panel is using the BFSK format. Additionally, this may be used as a summary relay option (see Point
Assignment in the D7212G Program Entry Guide [P/N: 4998138538]).
•
Eighth column (Custom Point Text): the
text displayed at command centers for the point. The text is transmitted to the receiver when the panel is using
the Modem IIIa
2
format.
D7212G
Default values are shown in ( ) or in
bold
RADXPNTS Handler
Point Assignments (001 through 040)
POPIT Switch
Setting
Trans-
lation
Point
#
Point
Index
Area
Assign
Debounce
BFSK/
Relay
Custom Point Text
100 001 __ __ (1) ____ (2) _____ (1) ____ P1 FIRE ___________________
200 002 __ __ (1) ____ (2) _____ (2) ____ P2 PANIC ___________________
300 003 __ __ (1) ____ (2) _____ (3) ____ P3 DELAY ___________________
400 004 __ __ (1) ____ (2) _____ (4) ____ P4 FOLLOW ___________________
500 005 __ __ (1) ____ (2) _____ (5) ____ P5 INSTANT
___________________
600 006 __ __ (1) ____ (2) _____ (6) ____ P6 INSTANT ___________________
700 007 __ __ (1) ____ (2) _____ (7) ____ P7 INSTANT ___________________
800 008 __ __ (1) ____ (2) _____ (8) ____ P8 INSTANT ___________________
0 1 2 3 4 5 6 101 009 __ __ (1) ____ (2) _____ (1) ____ P9 ___________________
0 1 2 3 4 5 _ 102 010 __ __ (1) ____ (2) _____ (1) ____ P10 ___________________
0 1 2 3 4 _ 6 103 011 __ __ (1) ____ (2) _____ (1) ____ P11 ___________________
0 1 2 3 4 _ _ 104 012 __ __ (1) ____ (2) _____ (1) ____ P12 ___________________
0 1 2 3 _ 5 6 105 013 __ __ (1) ____ (2) _____ (1) ____ P13 ___________________
0 1 2 3 _ 5 _ 106 014 __ __ (1) ____ (2) _____ (1) ____ P14 ___________________
0 1 2 3 _ _ 6 107 015 __ __ (1) ____ (2) _____ (1) ____ P15 ___________________
0 1 2 3 _ _ _ 108 016 __ __ (1) ____ (2) _____ (1) ____ P16 ___________________
0 1 2 _ 4 5 6 109 017 __ __ (1) ____ (2) _____ (1) ____ P17 ___________________
0 1 2 _ 4 5 _ 110 018 __ __ (1) ____ (2) _____ (1) ____ P18 ___________________
0 1 2 _ 4 _ 6 111 019 __ __ (1) ____ (2) _____ (1) ____ P19 ___________________
0 1 2 _ 4 _ _ 112 020 __ __ (1) ____ (2) _____ (1) ____ P20 ___________________
0 1 2 _ _ 5 6 113 021 __ __ (1) ____ (2) _____ (1) ____ P21 ___________________
Figure 14: Program Record Sheet
