Appendix B: Point Address Chart
Appendix B: Point Address Chart
B.1 ZONEX 1, Points 9 to 40
Place the labels on the base of the POPIT. Do not attach labels to the POPIT cover.
A number in the switch column indicates that the switch is set to ON.
D8127 or D9127 POPITs may be used for Points 9 to 40. D8127 POPITs have dipswitches 1 to 6, whereas D9127 POPITs have
dipswitches 0 to 6.
Switch
Address 0 1 2 3 4 5 6
009 0123456
010 0 1 2 3 4 5
011 0 1 2 3 4 6
012 0 1 2 3 4
013 0 1 2 3 5 6
014 0 1 2 3 5
015 0 1 1 3 6
016 0 1 2 3
017 0 1 2 4 5 6
018 0 1 2 4 5
019 0 1 2 4 6
020 0 1 2 4
021 012 56
022 0 1 2 5
023 0 1 2 6
024 0 1 2
025 01 3456
026 0 1 3 4 5
027 0 1 3 4 6
028 0 1 3 4
029 0 1 3 5 6
030 0 1 3 5
031 0 1 3 6
032 0 1 3
033 0 1 4 5 6
034 0 1 4 5
035 0 1 4 6
036 0 1 4
037 01 56
038 0 1 5
039 0 1 6
040 0 1
Table 16: ZONEX 1 Point Address Chart
