Qty Component
1 Split cable for loop through to 25-pin D-connector (only for DIVAR5000 hybrid
models)
1 RJ11 adapter cable to connect Bosch Intuikey keyboard (only on DIVAR5000
models)
Installation guides for Recorder, HDD, plus safety instructions
4.2 Make connections
Notice!
Use only PoE approved devices.
1. Connect the cameras to the or connectors.
– If using PoE connector, power is supplied to the camera via the Ethernet cable
compliant with the Power-over-Ethernet standard.
– Use an external switch to connect more cameras to a single RJ45 port.
2. Connect monitor A to the output, or the output.
3. Connect the USB mouse to a USB port (back or front panel).
Optional connections (depending on model)
– On DIVAR models, connect a second dual monitor to the HDMI MON.B (hybrid models) or
HDMI MON.A2 (network 5000 models) connector.
– Connect up to 4 audio signals to the RCA (CINCH) inputs (hybrid models only,
record audio only for analog input1, 2, 3 and 4).
– Connect 1 microphone to the RCA (CINCH) input (audio from the microphone is
only available via the network on the PC where the recorder Web Client is running).
– Connect 1 RCA (CINCH) output from to the monitor or an audio amplifier
(audio out can be: live audio from IP cameras, recorded audio or audio from the PC
where the recorder Web Client is running).
– Connect up to 16 alarm inputs to the connector (via the supplied terminal
blocks) - see description in Hardware setup.
– Connect up to 6 alarm outputs to the connector (via the supplied terminal
blocks) - see description in Hardware setup.
– Connect a pan/tilt/zoom control unit to the (only for hybrid models) - see
description in Hardware setup.
– Connect to your network via the RJ45 ETHERNET connector (use Shielded Twisted
Pair Category 5e cable).
– Connect extra video out cables to the ports if loop through is required to other
devices (only for DIVAR5000 hybrid).
– Connect a Bosch Intuikey keyboard cable to the connector using the supplied
adaptor (only for DIVAR5000) - see description in Hardware setup.
– Connect an eSATA storage device to the connector (only for DIVAR5000).
– Connect the DIVAR to an approved ground point. Use the ground screw (supplied in the
accessory bag) to attach a ground cable to the DIVARback panel ground point .
