Bosch DIVAR hybrid 3000 User Manual

12 en | Installation DIVAR 2000 | DIVAR 3000 | DIVAR 5000
2020-05 | V4.0 | AM18-Q0712 Installation manual Bosch Security Systems B.V.
4.2.1 Back panel connectors DIVAR network 2000/3000 (no PoE)
RJ45 video input for max. 32 IP cameras (max. 16IP cameras
for DIVAR2000) connected via external switch (optional with
DHCP configuration)
RJ45 Ethernet connection (10/100/1000Base-T according to
IEEE802.3)
1 D-SUB (Monitor output)
1 HDMI (Monitor output)
4 screw terminal inputs, cable diameter AWG26‑16
(0.4-1.29mm)
2 screw terminal outputs, cable diameter AWG26‑16
(0.4-1.29mm)
1 RCA (Audio output)
1 RCA (Audio input)
Screw terminal output
DB9 male, 9-pin D-type
One USB (3.0) connector for mouse or USB memory device;
one USB (2.0) also on front panel
Power input with On/Off
switch
12VDC (5A)
AC input adapter: 100~240VAC, 50-60Hz, 1.5A
Ground connection
