14 en | Installation DIVAR 2000 | DIVAR 3000 | DIVAR 5000
2020-05 | V4.0 | AM18-Q0712 Installation manual Bosch Security Systems B.V.
4.2.3 Back panel connectors DIVAR network 2000/3000 (16 PoE)
PoE Max. 16 PoE ports (130W; 25.5W max. per port) connected
with DHCP configuration (max. 16 IP cameras for
DIVAR2000; max 32 IP cameras for DIVAR3000)
RJ45 Ethernet connection (10/100/1000Base-T according to
IEEE802.3)
1 D-SUB (Monitor output)
1 HDMI (Monitor output)
4 screw terminal inputs, cable diameter AWG26‑16 (0.4–
1.29mm)
2 screw terminal outputs, cable diameter AWG26‑16 (0.4–
1.29mm)
1 RCA (Audio output)
1 RCA (Audio input)
Screw terminal output
DB9 male, 9-pin D-type
One USB (3.0) connector for mouse or USB memory device;
one USB (2.0) also on front panel
Power input with On/Off
switch
100~240VAC, 50-60Hz, 3.5A, 190W
Ground connection
