Bosch DIVAR IP 3000 - Power Supply; Device Views

8 en | System overview DIVAR IP 3000
2.2.3
2.3
Power supply
The chassis features a highly energy-efficient power supplies.
Device views
There are several LEDs on the front and rear of the chassis. The LEDs show the over-all status
of the system and the activity and health of specific components.
Front view:
1
52 3
4
6
1 Lock for front cover 4 LAN activity LED
2 Power on/off LED 5 System status LED
3 Hard disk access LED 6 Individual hard disk LED
2013.09 | V2 | DOC Installation Manual Bosch Sicherheitssysteme GmbH
