1 689 979 086 2018-06-08| Robert Bosch GmbH
12 | EFEP 60H / EFEP 67D | Symbols useden
1. Symbols used
1.1 In the documentation
1.1.1 Warning notices -
Structure and meaning
Warning notices warn of dangers to the user or
people in the vicinity. Warning notices also indicate
the consequences of the hazard as well as preventive
action. Warning notices have the following structure:
Warning
symbol
KEY WORD – Nature and source of hazard!
Consequences of hazard in the event of
failure to observe action and information
given.
¶ Hazard prevention action and information.
The key word indicates the likelihood of occurrence
and the severity of the hazard in the event of non-
observance:
Key word Probability of
occurrence
Severity of danger if
instructions not observed
DANGER Immediate impending
danger
Death or severe injury
WARNING Possible impending
danger
Death or severe injury
CAUTION Possible dangerous
situation
Minor injury
1.1.2 Symbols in this documentation
Symbol Designation Explanation
!
Attention Warns about possible property damage.
i
Information Practical hints and other
useful information.
1.
2.
Multi-step
operation
Instruction consisting of several steps.
e
One-step
operation
Instruction consisting of one step.
Intermediate
result
An instruction produces a visible
intermediate result.
"
Final result There is a visible final result on
completion of the instruction.
1.2 On the product
! Observe all warning notices on products and ensure
they remain legible.
1. Symbols used 12
1.1 In the documentation 12
1.1.1 Warning notices -
Structure and meaning 12
1.1.2 Symbols in this documentation 12
1.2 On the product 12
2. Product description 13
2.1 Safety instructions 13
2.2 Application 13
2.3 Delivery specification and special accessories 13
2.4 Device specification 13
2.4.1 EFEP 60H 13
2.4.2 EFEP 67D 14
2.4.3 Switching off the pressure gauge 14
2.5 Initial startup 14
2.6 Shutting down 14
3. Preparing for testing 15
3.1 Preconditions 15
3.2 Cleaning the nozzles 15
3.3 Connecting the nozzle and holder assembly 15
4. Testing 16
4.1 Test conditions 16
4.2 Visual inspection 16
4.3 Opening pressure 17
4.4 Tightness of fitting 17
4.5 Assembly leak test 17
4.6 Jet shape 18
4.7 Chatter behavior 18
5. Maintenance 19
5.1 Maintenance 19
5.2 Spare and wearing parts 19
6. Decommissioning 19
6.1 Change of location 19
6.2 Disposal and scrapping 19
6.2.1 EFEP 60H / EFEP 67D and accessories 19
6.2.2 Substances hazardous to water 19
7. Technical data 19
7.1 Pressure gauge 19
7.2 Test oil tank 19
7.3 Tightening torques 19
Contents English
