2:9
From the underside of the manifold panel remove the two screws at the
outside corners that secure the manifol panel to the oven chassis
.
Photo D
E
F
Screw Locations
Igniter
Switches
From the top side of the manifold panel, remove the screws which
secure the two cooktop lock clips and remove the clips (photo E). The
manifold panel can now be removed by pulling forward.
With the panel removed, the surface burner igniter switches are
accessible (photo F). The switches are connected together in a
harness and must be replaced as a complete assembly.
