Gas Cooktop Operation
Cooktop Configuration and Burner Specifications
300 Series gas ranges are equipped with five sealed-type surface
burners with electronic spark ignition. Surface burner sizes on the 300
series are 12,000 9500 (2) 5000 14,200 BTU. The illustration at
right shows the cooktop layout, burner configuration and BTU rating of
each surface burner location.
300 Series Cooktop
500 Series Cooktop
500 Series gas ranges are equipped with five sealed-type surface
burners with electronic spark ignition. Surface burner sizes on the 500
series are 12,000 9500 (2) 5000 16,000 BTU. The center burner of
the 500 series range is an elongated oval burner ideal for using griddles
or other oblong cookware. The illustration at right shows the cooktop
layout, burner configuration, and BTU rating of each surface burner
location.
12k
9.5k
9.5k
5k
14.2k
12k
9.5k
5k
16k
9.5k
