Oven Bake Burner
Photo A
To access the oven bake burner first remove the oven 2YHQ
'RRUDQG+LQJHVated by the arrows
in photo A.
If the range has a convection fan convection
Lift the rear edge of the oven bottom up about 3 inches and
slide ittoward the rear oven wall (hoto B)
the oven bottom to release from the front cross brace of the chassis.
The oven bottm can then be removed fromthe oven.
Photo B
After removing the oven bottom remove the two screws that secure
the flame spreader/oven baffle to the chassis (hoto C)Lift the front edge
of the baffle up slightly and pull forward to remove the baffle from the oven.
C
