Panel Controller Notice | en 17
Bosch Sicherheitssysteme GmbH Installation Guide 2017.07 | 5.0 | F.01U.258.925
1 Notice
Notice!
Installation must only be carried out by authorized specialist personnel.
Warning!
Live components and stripped cable! Risk of injury from electric shock. The system must be
current-free during connection work.
Notice!
The DVD includes the FSP-5000-RPS Programming Software and the required product
documentation of the panel.
Notice!
Bosch Sicherheitssysteme GmbH uses open source software within this product. The
declaration of the components and their respective licenses can be found on http://
www.boschsecurity.com/oss/.
Notice!
Use the MPC-XXXX-C Panel Controller only with the PRS-0002-C Short Rail.
Use solely the 5-wire cable of the Panel Controller for connection to the Panel Rail Short.
Notice!
Except for the BCM Battery Controller Module, all other modules do not work, if plugged onto
the PRS0002 A short rail.
2 Functional Description
The Panel Controller controls every component connected to the panel and features the
following functional elements (see Figures, page 4):
Pos. Designation Function
A Touch screen Operating the panel through virtual buttons and variable display windows
B 22 fixed buttons Standard entries
C 12 LEDs Indicating the operating status
D Key switch 2 switch settings, freely programmable, e.g. for switching between day/night
mode, or connection/disconnection to and from the local alarm signaling
E 3 rotary switches Address setting
F Reboot button Panel HW reset
G 6-pin DIP switch Configuration
H Ground wire Grounding the panel
