Bosch GCM 12 SD - SYMBOLS; Cutting Movement, Transport, and Handle Adjustment Symbols

English–51 609 929 F67 • (04.10) PS
Note symbol Perform the cuts with sliding movements in the se#
quence shown.
Note symbol Take hold of the electro#tool for transporting at
these marked locations.
Note symbol Transport handle
Note symbol Danger of pinching! Place the finger around the
transport handle when transporting.
Note symbol Shows the individual steps for adjusting the han#
dle.
Symbol Meaning
