English–161 609 929 F67 • (04.10) PS
Fence
Place the electro#tool in the transport position.
Rotate the saw table 18 to the detent 17 for 0°.
Checking: (see Figure
)
Set the combination square to 90° and place it on the
saw table 18. The square must be flush with the fence
20 over its entire length.
Adjusting: (see Figure
)
Unscrew the knobs 22 of the fence extensions on both
sides completely out and loosen the adjustment screw
67 with the hex#head bit 35 (SW 4). Remove the fence
extensions.
Loosen all hex#head bolts 68 with the socket spanner
35 (SW 14). Rotate the fence 20 until the protractor is
flush over its entire length. Retighten the hex#head
bolts.
Remount the fence extensions. Tighten the adjust#
ment screws 67 only far enough so that the fence ex#
tensions can be easily slid.
6 MAINTENANCE AND SERVICE
Maintenance
Before all work on the machine, pull the mains
plug.
Always keep the machine and the ventilation slits clean
for efficient and safe working.
The swinging guard must always be able to move free#
ly and close by itself. Therefore, always keep the area
around the swinging guard clean.
Remove dust and chips by blowing out with com#
pressed air or with a brush.
Should the tool fail in spite of careful manufacturing
and testing procedures, have the repairs performed by
an authorised customer service location for Bosch
Electro#Tools.
For inquiries and spare parts ordering, please include
the 10#digit order number on the nameplate of the
tool.
Disposal
Tool, accessories and packaging should be sorted for
environment#friendly recycling.
The plastic components are labelled for categorised
recycling.
Accessories
Saw blade 305 x 30 mm, 60 teeth. . . 2 608 640 441
Saw blade 305 x 25.4 mm, 80 teeth . 2 610 915 721
Quick#action clamps
Vertical . . . . . . . . . . . . . . . . . . . . . . . 2 608 040 205
Horizontal . . . . . . . . . . . . . . . . . . . . . 2 608 040 236
Table inserts . . . . . . . . . . . . . . . . . . . 2 607 960 020
Dust bag set . . . . . . . . . . . . . . . . . . . 2 605 411 211
Extension bars (435 mm),
4 Pieces . . . . . . . . . . . . . . . . . . . . . . 2 607 001 956
Service
Exploded views and information on spare parts can be
found under: www.bosch#pt.com
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham#Uxbridge
Middlesex UB 9 5HJ
Service . . . . . . . . . . . . . . .+44 (0) 18 95/83 87 82
Advice line . . . . . . . . . . . .+44 (0) 18 95/83 87 91
Fax . . . . . . . . . . . . . . . . . . . .+44 (0) 18 95/83 87 89
Ireland
Beaver Distribution Ltd.
Greenhills Road
Tallaght#Dublin 24
Service . . . . . . . . . . . . . . . . .+ 353 (0)1/414 9400
Fax . . . . . . . . . . . . . . . . . . . . . .+ 353 (0)1/459 8030
Australia
Robert Bosch Australia Ltd.
RBAU/SBT2
1555 Centre Road
P.O. Box 66 Clayton
3168 Clayton/Victoria
. . . . . . . . . . . . . . . . . . . . . .+61 (0)1/800 804 777
Fax . . . . . . . . . . . . . . . . . . . . .+61 (0)1/800 819 520
www.bosch.com.au
E#Mail: CustomerSupportSPT@au.bosch.com
New Zealand
Robert Bosch Limited
14#16 Constellation Drive
Mairangi Bay
Auckland
New Zealand
. . . . . . . . . . . . . . . . . . . . . . . +64 (0)9/47 86 158
Fax . . . . . . . . . . . . . . . . . . . . . . .+64 (0)9/47 82 914
Specifications subject to alteration without notice
