Bosch GLM 30 Operating/Safety Instructions

-9-
Technical Data
Digital Laser Measure
GLM 30 R / GLM 30 S / GLM 30
Article Number
GLM 30
GLM 35
3601K72B10
3601K72B12
Measuring range (typical)
GLM 30
GLM 35
6 in - 100 ft (0.15 - 30 m)
A
6 in - 120 ft (0.15 - 35 m)
A
Measuring accuracy (typical) ± 1/16 in (± 1.5 mm)
B
Lowest indication unit ± 1/32 in (1 mm)
Operating temperature +14 °F to 113 °F (-10 °C to 45 °C)
Storage temperature -4 °F to 158 °F (-20 °C to 70 °C)
Relative air humidity, max 90%
Laser class 2
Laser type 635nm, <1mW
Automatic switch-off after approx.
- Laser 20 s
- Measuring Tool 5 min
Degree of Protection IP54
(dust and splash water protected)
C
Batteries 2 x 1.5V (AAA)
Battery service life in measuring
operation, approx
4 h
Weight 0.22 lb (0.1 kg)
Dimensions 4.1 x 1.6 x 0.9 in
(105 x 41 x 24 mm)

Bosch GLM 30 Specifications

General

Accuracy	± 2 mm
Laser Class	2
Laser Type	635 nm, <1 mW
Power Supply	2 x 1.5 V LR03 (AAA)
Dimensions	105 x 41 x 24 mm
Measurement Time, typical	0.5 s
Measurement Time, max.	4 s
Automatic Deactivation	5 min
Operating Temperature	-10 – 50 °C
Protection Class	IP54
Measurement Range	0.15 – 30 m
Units of Measurement	m
Battery Life	5000 individual measurements
Display	Illuminated display
