-11-
Operation
Initial Operation
!
WARNING
Protect the tool against moisture and direct
sun irradiation.
Do not subject the tool to extreme temperatures or variations
in temperature. As an example, do not leave it in vehicles for
longer periods. In case of large variations in temperature, allow
the tool to adjust to the ambient temperature before putting it
into operation. In case of extreme temperatures or variations in
temperature, the accuracy of the tool can be impaired.
Avoid heavy impact or falling of the tool. After heavy exterior
impact on the tool, an accuracy check should always be carried
out before continuing to work (see “Accuracy Check of the
Distance Measurement”, page 16) each time before continuing
to work.
!
WARNING
Do not point the laser beam at persons or
animals and do not look into the laser
beam yourself, not even from a large distance.
Do not leave the switched on measuring tool unattended and
switch the tool off after use. Other persons could be blinded
by the laser beam.
Switching On and Off
– To switch on the measuring tool and the laser, press the
measuring button
2
or the Clear/ On/Off button
5
.
To
switch off
the measuring tool, press and hold the Clear/ On/
Off button
5
.
Measuring Procedure (see figure A)
Once switched on, the measuring tool is in the real time
measurement function. Laser is automatically activated and tool is
measuring. You can set other measuring functions by repeatedly
pressing button 4 (see “Measuring Functions”, page 11).
The rear edge of the measuring tool is always the reference point
for the measurement.
Place the measuring tool against the desired starting point of the
measurement (e.g. a wall).
