19
Bluetooth
®
Bluetooth
®
(4.1 low-energy)
F)
Operating frequency band 2402 – 2480 MHz
A) For measurements from the front edge of the measuring tool, applies to high
reflectivity of the target (e.g. a white-painted wall), weak backlighting and 25°C
operating temperature. In addition, a deviation of ±0,05mm/m must be taken
into account.
B) For measurements from the rear edge of the measuring tool, applies to low
reflectivity of the target (e.g. a dark-painted wall), strong backlighting and – 10°C
to +45°C operating temperature. In addition, a deviation of ±0.15 mm/m must be
taken into account.
C) After calibration at 0° and 90° with an additional pitch error of max. ±0.01°/
degrees up to 45°. The measurement accuracy is related to the 3 orientations
based on the calibration of the inclination (tilt measurement), see picture H.
D) At 25°C operating temperature.
E) In the continuous measurement function, the maximum operating temperature
is +40°C.
F) When using Bluetooth
®
Low Energy tools, it may not be possible to establish a
connection depending on the model and operating system. Bluetooth
®
devices
must support the GATT profile.
G) Automatic switch-off of the measuring tool is adjustable after 2, 5, 10 minutes
or never.
H) The left-hand side of the measuring tool serves as the reference level for grade
measurement.
A long battery runtime is achieved by means of energy-saving measures, such
as deactivating the Bluetooth
®
function when not required, or reducing the display
brightness, etc.
The measuring tool can be clearly identified with the serial number 15 on the type
plate.
2610049010 10-17 GLM400C.indd 19
11/3/17 1:09 PM

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Bosch GLM400C and is the answer not in the manual?

Bosch GLM400C Specifications

General IconGeneral
Accuracy±1.5 mm
ConnectivityBluetooth
ProtectionIP54
Laser Diode635 nm, < 1 mW
Measuring range of incline measurement0 – 360° (4 x 90°)
Measuring accuracy (incline measurement)±0.2°
Measurement time, typical< 0.5 s
Measurement time, max.4 s
Automatic deactivation5 min
Tripod thread1/4"
Laser Class2
Units of measurementm, ft
Memory capacity50 measurements
Storage Temperature-20°C to 70°C
DisplayColor display with backlight
