28
Area Measurement
Select the area measurement
.
Then measure the width and length one after the other as with
a length measurement. The laser beam remains switched on
between the two measurements. The distance to be measured
flashes in the indicator for area measurement
.
09.06.2017
13:20:23
0.0º
728.167 ft
2
25´00˝
29´02˝
The first measured value is shown at the top of the
display.
After the second measurement has been completed,
the area will be automatically calculated and
displayed. The end result is shown at the bottom of
the display, while the individual measured values are
shown above it.
Volume Measurement
Select the volume measurement
.
Then measure the width, length and depth one after the other as
with a length measurement. The laser beam remains switched on
between the three measurements. The distance to be measured
flashes in the indicator for volume measurement
.
09.06.2017
13:20:23
0.0º
25´00˝
29´02˝
15´03˝
11124.1 ft
3
The first measured value is shown at the top of the
display.
After the third measurement has been completed,
the volume will be automatically calculated and
displayed. The end result is shown at the bottom of
the display, while the individual measured values are
shown above it.
Indirect Distance Measurement
Select the indirect distance measurement
.
There are four measuring functions available for the indirect
distance measurement, each of which is capable of determining
different distances.
The indirect distance measurement is used to measure distances
that cannot be measured directly because an obstacle would
obstruct the laser beam or no target surface is available as a
reflector. This measuring procedure can only be used in vertical
direction. Any deviation in horizontal direction leads to measuring
errors.
Note: Indirect distance measurement is always less accurate
