ICP-CC488 | User's Guide | 21. Basic Pager Reporting EN | 19
Bosch Security Systems, Inc. | 12/08 | F01U089456-02
Figure 9: Basic Pager Display
1 – Subscriber ID number
2 – Zone status
3 – System status
4 – 0 – Zone Normal
1– Alarm
2 – Manually Isolated
3 – Auto Isolated
5 – 8 – Disarmed
9 – Armed
6 – 0 – Normal
1 – Panic/Duress
2 – Fire Alarm
3 – Medical Alarm
7 – 0 – AC Normal
1 – AC Failure
8 – 0 – System Normal
1 – System Fault
