Bosch KGN362IBF - 13.3.4 Groente- en fruitlade verwijderen; 13.3.5 Diepvrieslade verwijderen; 13.3.6 Ladefront verwijderen

Cleaning and maintenance
2.Lift the front storage drawer and
remove it.
2.Lift the front freezer drawer and
remove it.
Remove
fruit and vegetable drawer Remove drawer front
1.Pull out the fruit and vegetable drawer as
far
as it will go.
You can remove the drawer front of
the fruit and vegetable drawer and
the frozen food drawer for easier
cleaning.
▶ Press the
click hooks on the side
of the drawer and remove the
drawer front by rotating the
drawer.
2.
Lift the fruit and vegetable drawer
at the front and remove it
.
Remove freezer
drawer
1.
Pull out the freezer drawer as far
as the stop.
23
