36 | Airflow Tables LM Series Heat Pump

LM Series Heat Pump8 733 905 315 (2013/9) Subject to change without prior notice

Constant Airflow Motor Airflow Table

(LM0**-***-***-A*

Figure # 23

ECM Const CFM Motor - EON

Models

Fan

Speed

Rated

Airflow

Adjust Tap

External Static Pressure (in of Water)

0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00

LM024

Part Load

Hi 725 + A725725 725 725 725 725 725 725 - -

Med 650 Normal A650650 650 650 650 650 650 650 - -

Low 500 - A500500 500 500 500 500 500 500 - -

LM024

Full Load

Hi 950 + A950950 950 950 950 950 950 950 - -

Med 825 Normal A825825 825 825 825 825 825 825 - -

Low 725 - A725725 725 725 725 725 725 725 - -

LM036

Part Load

Hi 950 + A950950 950 950 950 950 950 950 950 950

Med 800 Normal A800800 800 800 800 800 800 800 800 800

Low 750 - A750750 750 750 750 750 750 750 750 750

LM036

Full Load

Hi 1300 + A13001300 1300 1300 1300 1300 1300 1300 1300 1300

Med 1100 Normal A 1100 1100 1100 1100 1100 1100 1100 1100 1100 1100

Low 950 - A950950 950 950 950 950 950 950 950 950

LM048

Part Load

Hi 1400 + A 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400

Med 1300 Normal A13001300 1300 1300 1300 1300 1300 1300 1300 1300

Low 1100 - A 1100 1100 1100 1100 1100 1100 1100 1100 1100 1100

LM048

Full Load

Hi 1800 + A18001800 1800 1800 1800 1800 1800 1800 1800 1800

Med 1600 Normal A 1600 1600 1600 1600 1600 1600 1600 1600 1600 1600

Low 1400 - A 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400

LM060

Part Load

Hi 1800 + A18001800 1800 1800 1800 1800 1800 1800 1800 1800

Med 1600 Normal A 1600 1600 1600 1600 1600 1600 1600 1600 1600 1600

Low 1400 - A 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400

LM060

Full Load

Hi 2200 + A 2200 2200 2200 2200 2200 2200 2200 2200 2200 2200

Med 2000 Normal A 2000 2000 2000 2000 2000 2000 2000 2000 2000 2000

Low 1800 - A18001800 1800 1800 1800 1800 1800 1800 1800 1800

LM070

Part Load

Hi 2100 + A 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100

Med 1850 Normal A18501850 1850 1850 1850 1850 1850 1850 1850 1850

Low 1600 - A 1600 1600 1600 1600 1600 1600 1600 1600 1600 1600

LM070

Full Load

Hi 2500 + A 2500 2500 2500 2500 2500 2500 2500 2500 2500 2500

Med 2350 Normal A23502350 2350 2350 2350 2350 2350 2350 2350 2350

Low 2100 - A 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100
