22 en | Web Interface MIC IP fusion 9000i
2017.11 | 0.20 | F.01U.349.011 User Manual Bosch Security Systems
Image being viewed Imager that Detected Object Resulting outlines
Thermal Visible imager Dotted box
Thermal imager Solid box
Show VCA trajectories
The trajectories (motion lines of objects) from the video content analysis are displayed in the
live video image if a corresponding analysis type is activated. The trajectory is shown as a
green line following the object base point.
If the metadata fusion feature is enabled (that is, VCA is enabled for both the visible and
thermal image streams), trajectory lines will appear on both the visible and thermal image
streams.
The following table identifies the trajectory lines that appear.
Image being viewed Imager that Detected Object Resulting trajectory lines
Visible Visible imager Solid green line
Thermal imager Dotted green line
Thermal Visible imager Dotted green line
Thermal imager Solid green line
Note: For details about how VCA objects appear on the Live page, refer to the section
Understanding the Fusion Feature, page 77.
Show overlay icons
Select this check box to show overlay icons on the live video image.
Show VCA items
Shows alarm fields, lines and routes configured for the video analytics in the following colors:
– Green: Fields, lines and routes used in a task are displayed in green. They can be edited
but not deleted.
– Red: Fields, lines and routes currently in alarm mode are displayed in red.
Latency mode
Select the required latency mode:
– Low delay: Default mode. Provides marginal buffering to display fluent video under
normal network conditions.
– Smooth video: Allows the buffer to automatically adjust to cover network jitter, inducing
higher latency.
– Unbuffered: Displays video as it is received by the decoder with minimum latency. Allows
the video to jerk if there is network jitter.
JPEG resolution
You can specify the size of the JPEG image on the Live page. Options are Small, Medium,
Large, 720p, 1080p, and “Best possible” (default).
JPEG interval
You can specify the interval at which the individual images should be generated for the M-
JPEG image on the Live page.
JPEG quality
You can specify the quality at which the JPEG images appear on the Live page.
