Operating instructions
|
OBD 1110
|
en
|
OBD 1110
|
Operating instructions | 11
en
577383 REV A | 10.2015 Bosch Automotive Service Solutions 577383 REV A | 10.2015Bosch Automotive Service Solutions
PID PID description
AECD8_
TIME1, TIME 2
Total Run Time with EI-AECD
#8 Timer 1 Active, #2 Timer
Active
AECD9_
TIME1, TIME 2
Total Run Time with EI-AECD
#9 Timer 1 Active, #2 Timer
Active
ALCOHOL Alcohol Fuel Percent
BARO PRS Barometric Pressure
BAT_PWR
Hybrid Battery Pack Remain
-
ing Life
BP_A_ACT, B_
ACT
Boost Pressure Sensor A, Sen
-
sor B
BP_A_CMD,
B_CMD
Commanded Boost Pressure
A, Pressure B
BP_A_STAT, B_
STAT
Boost Pressure A Control Sta
-
tus, B Control Status
CACT 11, 12
Charge Air Cooler Temper
-
ature Bank 1 Sensor 1 sup-
ported, Sensor 2 supported
CACT 21,22
Charge Air Cooler Temper
-
ature Bank 2 Sensor 1 sup-
ported, Sensor 2 supported
CALC LOAD Calculated Engine Load
CAT TEMP11,
TEMP12
Cataltic Converter Temp
Bank1, Temp Bank 3
CAT TEMP21,
TEMP22
Cataltic Converter Temp
Bank2, Temp Bank 4
CLR DIST Distance since erase
CLR TIME Minutes Run since Erase
CLR TRPS Warmups Since Erase
CMD EQ RAT
Commanded Equivalence
Ratio
COOLANT Engine Coolant Temp
DPF_REG_
AVGD
Average Distance Between
DPF Regen
DPF_REG_
AVGT
Average Time Between DPF
Regen
DPF_REG_
STAT
Diesel Particulate Filter (DPF)
Regen Status
DPF_REG_TYP
Diesel Particulate Filter (DPF)
Regen Type
DPF_REGEN_
PCT
Normalized Trigger for DPF
Regen
PID PID description
DPF1_DP,
DPF2_DP
Diesel Particulate Filter (DPF)
Bank 1 Delta Pressure Bank 2
Delta Pressure
DPF1_INP,
DPF2_INP
Diesel Particulate Filter (DPF)
Bank 1 Inlet Pressure, Bank 2
Inlet Pressure
DPF1_INT,
DPF2_INT
DPF Bank 1 Inlet Temperature
Sensor, Bank 2 Inlet Tempera
-
ture Sensor
DPF1_OUTP,
DPF2_OUTP
Diesel Particulate Filter (DPF)
Bank 1 Outlet Pressure,
Bank 2 Outlet Pressure
DPF1_OUTT,
DPF2_OUTT
DPF Bank 1 Outlet Temper
-
ature Sensor, Bank 2 Outlet
Temperature Sensor
ECT 1, 2
Engine Coolant Temperature
1, Temperature 2
EGR CMD Comanded EGR
EGR ERR
Exhaust Gas Recirculation
Error
EGR_A_ACT,
B_ACT
Actual EGR A Duty Cycle / Posi
-
tion, B Duty Cycle / Position
EGR_A_CMD,
B_CMD
Commanded EGR A Duty
Cycle / Position, B Duty Cycle /
Position
EGR_A_ERR,
B_ERR
EGR A Error, B Error
EGRT 11, 21
Exhaust Gas Recirculation
Temperature Bank 1 Sensor 1,
Bank 2 Sensor 1
EGRT 12, 22
Exhaust Gas Recirculation
Temperature Bank 1 Sensor 2,
Bank 2 Sensor 2
EGT 11, 21
Exhaust Gas Temperature
(EGT) Bank 1 Sensor 1, Bank
2 Sensor 1
EGT 12, 22
Exhaust Gas Temperature
(EGT) Bank 1 Sensor 2, Bank
2 Sensor 2
EGT 13, 23
Exhaust Gas Temperature
(EGT) Bank 1 Sensor 3, Bank
2 Sensor 3
EGT 14, 24
Exhaust Gas Temperature
(EGT) Bank 1 Sensor 4, Bank
2 Sensor 4
EMIS_SUP
Emission requirements to
which vehicle is designed
ENG RUN Time Since Engine Start
Troubleshooting
 If a “LINK ERROR” message
appears, cycle the ignition
key to the OFF position for
10 seconds, then back ON,
then press the
 ENTER
key. Make sure the ignition
key is in the ON not the
ACCESSORY position.
 If the MIL Status is ON and
the MIL is not illuminated
with the engine running,
then a problem exists in the
MIL circuit.
PID Definitions
NOTICE
Although over 300
PIDS are available,
the tool only displays
the PIDs the vehicle
supports.
PID PID description
ABS FRP Absolute Fuel Rail Pressure
ABS LOAD Absolute Load Value
ABS TPS B, C Throttle Position B, C
ABSLT TPS Absolute Throttle Position
ACC POS D Accelerator Pedal D, E, F
ACC POS REL
Relative Accelerator Pedal
Position
AECD1_TI
-
ME1, TIME 2
Total Run Time with EI-AECD
#1 Timer 1 Active, #2 Timer
Active
AECD10_TI
-
ME1, TIME 2
Total Run Time with EI-AECD
#10 Timer 1 Active, #2 Timer
Active
PID PID description
AECD11_TI
-
ME1, TIME 2
Total Run Time with EI-AECD
#11 Timer 1 active, #2 Timer
Active
AECD12_TI
-
ME1, TIME 2
Total Run Time with EI-AECD
#12 Timer 1 active, #2 Timer
Active
AECD13_TI
-
ME1, TIME 2
Total Run Time with EI-AECD
#13 Timer 1 active, #2 Timer
Active
AECD14_TI
-
ME1, TIME 2
Total Run Time with EI-AECD
#14 Timer 1 active, #2 Timer
Active
AECD15_TI
-
ME1, TIME 2
Total Run Time with EI-AECD
#15 Timer 1 active, #2 Timer
Active
AECD16_TI
-
ME1, TIME 2
Total Run Time with EI-AECD
#16 Timer 1 active, #2 Timer
Active
AECD17_TI
-
ME1, TIME 2
Total Run Time with EI-AECD
#17 Timer 1 active, #2 Timer
Active
AECD18_TI
-
ME1, TIME 2
Total Run Time with EI-AECD
#18 Timer 1 active, #2 Timer
Active
AECD19_
TIME1, TIME 2
Total Run Time with EI-AECD
#19 Timer 1 active, #2 Timer
Active
AECD2_
TIME1, TIME 2
Total Run Time with EI-AECD
#2 Timer 1 Active, #2 Timer
Active
AECD20_
TIME1, TIME 2
Total Run Time with EI-AECD
#20 Timer 1 active, #2 Timer
Active
AECD3_
TIME1, TIME 2
Total Run Time with EI-AECD
#3 Timer 1 Active, #2 Timer
Active
AECD4_
TIME1, TIME 2
Total Run Time with EI-AECD
#4 Timer 1 Active, #2 Timer
Active
AECD5_
TIME1, TIME 2
Total Run Time with EI-AECD
#5 Timer 1 Active, #2 Timer
Active
AECD6_
TIME1, TIME 2
Total Run Time with EI-AECD
#6 Timer 1 Active, #2 Timer
Active
AECD7_
TIME1, TIME 2
Total Run Time with EI-AECD
#7 Timer 1 Active, #2 Timer
Active
