Bosch OBD1110 - Emissions Monitoring and Freeze Data

14
|
Operating instructions
|
OBD 1110
|
en
|
OBD 1110
|
Operating instructions | 15
en
577383 REV A | 10.2015 Bosch Automotive Service Solutions 577383 REV A | 10.2015Bosch Automotive Service Solutions
Limited Warranty
This warranty is expressly lim-
ited to original retail buyers
of Bosch electronic diagnostic
tools (“Units”).
Bosch Units are warranted against
defects in materials and work-
manship for one year (12 months)
from date of delivery. This war-
ranty does not cover any Unit that
has been abused, altered, used
for a purpose other than that for
which it was intended, or used
in a manner inconsistent with
instructions regarding use. The
sole and exclusive remedy for
any Unit found to be defective is
repair or replacement, the option
of Bosch. In no event shall Bosch
be liable for any direct, indirect,
special, incidental or consequen-
tial damages (including lost profit)
whether based on warranty,
contract, tort or any other legal
theory. The existence of a defect
shall be determined by Bosch
in accordance with procedures
established by Bosch. No one is
authorized to make any statement
or representation altering the
terms of this warranty.
Disclaimer
The above warranty is in lieu of
any other warranty, express or
implied, including any warranty
of merchantability or fitness for a
particular purpose.
Software
Unit software is proprietary,
confidential information protected
under copyright law. Users have
no right in or title to Unit software
other than a limited right of use
revocable by Bosch. Unit soft-
ware may not be transferred or
disclosed without written consent
of Bosch. Unit software may not
be copied except in ordinary
backup procedures.
Technical Support /
Repair Service
If you have any questions on
the operation of the product,
please call 1300 783 031 or
email automotive.
techsupport@au.bosch.com.
Please contact Technical Support
for troubleshooting and service
options prior to sending any unit
for repair.
For repair, return the unit to point
of purchase.
PID PID description
VEH SPEED Vehicle Speed
VGT_A_ACT,
B_ACT
Variable Geometry Turbo A
Position, Turbo B
VGT_A_CMD,
B_CMD
Commanded Variable Geome
-
try Turbo A Position, Turbo B
VGT_A_STAT,
B_STAT
Variable Geometry Turbo A
Control Status, Turbo B
VPWR Control Module Voltage
WG_A_ACT, B_
ACT
Wastegate A Position, B
Position
WG_A_CMD,
B_CMD
Commanded Wastegate A
Control, B Control
TQ_DD Driver's demand engine per
-
cent torque
TQ_ACT Actual engine percent torque
TQ_MAX1,
MAX2, MAX3,
MAX4, MAX5
Engine percent torque at
idle point 1, 2, 3, 4, 5
TQ_REF Engine reference torque
VGT_A_ACT Variable geometry turbo A
position
VGT_A_CMD Commanded variable geome
-
try turbo A position
VGT_A_STAT Variable geometry turbo A con
-
trol status
VGT_B_ACT Variable geometry turbo B
position
VGT_B_CMD Commanded variable geome
-
try turbo B position
VGT_B_STAT Variable geometry turbo B con
-
trol status
VPWR Control module voltage
WG_A_ACT Wastegate A position
WG_A_CMD Commanded wastegate A
control
WG_B_ACT Wastegate B position
WG_B_CMD Commanded wastegate B
control
