Bosch Security Systems | 2006-11 | 9922 141 50781 en
Plena 24 VDC Battery Charger | Installation and User Instructions | Technical data en | 21
5 Technical data
5.1 Electrical
5.2 Inputs
5.3 Indicators
5.4 System connection
5.5 Fault output
5.6 24 V DC out
5.7 Environmental conditions
5.8 General
Mains voltage
240/90 V(AC), ± 10%, 50/60 Hz
Power consumption
550 VA max
Minimum output voltage (automatic shutdown)
20 V
Maximum output voltage (Regulated independent
of battery)
25.5 V
Maximum charge current
10.0 A (maximum load)
Maximum system current
70 A
Auxiliary output current
24 VDC
Auxiliary current
3 A per output, 5 A total maximum load
Battery type
Lead - acid traction battery
Battery capacity
2 - 200 Ah
Temperature sensor
External - defeat
Supervision
On EMG inputs, programmable
Fault
Correct function of charger
Battery in use
Battery is being drained during normal condition
Battery
Battery is defective or not connected
Mains
Mains is not connected
24 VDC
100 A screw terminals
Fuse
70 A slow
Regulation polarity
RTN
Temperature sensor
Semiconductor with mounting eye
Fault output voltage
< 24 V
Type
Normally opened (default) or normally closed
24 VDC out
24 V(DC), max. 0.8 A
Operating temperature range
+5 to +55 °C
Storage temperature range
-25 to +55 °C
Relative humidity
< 95%
Make sure the charger is not exposed to sources of
water or water splashes.
EMC emission
According to EN55103-1
EMC immunity
According to EN55103-2
Dimensions
88 x 430 x 260 wide,
19“ rack installation 2 U high, 260 mm deep
(leave 50 mm for connections)
19” mounting brackets
included
Weight
3 kg
