IMAGER CABLE CONNECTOR
IMAGER ILLUMINATION
BRIGHTNESS INCREASE
VIEWING SCREEN
IMAGER ILLUMINATION
BRIGHTNESS DECREASE
ON/OFF SWITCH
RUBBERIZED GRIP
BATTERY PACK
FIG. 1
8-.57>6+.; PS90
Voltage rating 10.8V/12V MAX
*==.;B9*,4 BAT411, BAT412 & BAT413
1*;0.; BC330 & BC430
Voltage rating 120 V 60 Hz
Charge time BC330 (1 Hour)
BC430 (30 minutes)
26.7<287<&2=18>=*==.;B *,48627*5
Weight 6.8 oz (0.192 kg)
Length 6.5" (166mm)
Width 2.6" (66mm)
Depth 1.8" (45mm)
%2.@270",;..7
Resolution 320 x 240
Screen Type 2.7" LCD
9.;*=2707?2;876.7=
Temperature -4°F to 149°F (-20°C to 65°C)
Humidity 5% to 95% non-condensing (display unit)
"=8;*0.#.69.;*=>;. -22°F to 176°F (-30°C to 80°C)
%2-.8>=9>= NTSC
BATTERY
RELEASE TABS
ON SCREEN BATTERY
CHARGE INDICATOR
VIDEO OUTPUTPORT
(Backside of unit)
