22/104 Scope of delivery
Bosch Rexroth AG, A4... with HS5E pilot control valve/Series 3x, RE 92076-01-B/10.2017
4 Scope of delivery
3
5
2
7
4
1
6
Fig. 1: Axial piston unit with HS5E(P) control system, clockwise rotation with through drive
The scope of delivery includes the following:
• Axial piston unit with HS5E(P) control system as per order confirmation
The following parts are also assembled prior to delivery:
• Transport protection of the drive shaft with keyed shafts(1)
• Protective covers(2)
• Protective plug/threaded plug (3)
• For version with optional through drive closed with fail-safe cover(4)
• HS5E pilot control valve (5)
• Swivel angle sensor (6)
• Pressure transducer plus cable (7) (with HS5EP only)
