12/24 4THE5 | Scope of delivery
Bosch Rexroth AG, RE29696-01-B/2021-06-15
4 Scope of delivery
1
3
2
Fig. 1: 4THE5 electronic joystick
The scope of delivery is defined by fully assembled joysticks incl. bellow (3) or
stand-alone joystick base(1) or control-grip(2).
Multiple type of packaging exist according to the batch size ordered.
