20/24 4THE5 | Removal and replacement
Bosch Rexroth AG, RE29696-01-B/2021-06-15
10�2 Inspection and maintenance
No special activities are necessary.
10�3 Repair
The joystick base, the complete control grip and the large bellow are available as
spare parts. The joystick base itself cannot be repaired but only replaced.
Control grip components such as push-button, rocker or roller are not serviceable
for safety reasons.
▶ Only use original spare parts from Rexroth, otherwise the functional reliability
cannot be guaranteed, and the warranty will be voided.
▶ Spare parts can be found online at www.boschrexroth.com/eshop
Address all questions regarding repair to your responsible BoschRexroth service.
11 Removal and replacement
▶ Only disassemble the joystick when de-energized and depressurized.
12 Disposal
Careless disposal of the joystick can lead to environmental pollution.
▶ Dispose of the joystick and the packaging material in accordance with the
national regulations in your country.
13 Extension and conversion
Do not convert the joystick.
The warranty from BoschRexroth only applies to the configuration as delivered.
Entitlement to warranty cover will be rendered void in case of conversion,
extension or asoftware modification by customer.
