Fault description Cause Remedy
Motor does not run Brake is not released Check the brake activation
Vibrations Coupling elements or attachments are
poorly balanced
Re-balance
Adjustment of shaft end attachments
(coupling, gearbox, ...) is insufficient
Re-align the attachments
Mounting screws loose Lock screw connections acc.
to specifications
. .
Running noise Foreign bodies within the motor Stop the motor --> repair by
manufacturer
Bearing is damaged Stop the motor --> repair by
manufacturer
High motor temperatures;
motor temperature monitoring
is activated
Operation outside the parameters Reduce load and check the
dimensioning
Heat dissipation is impaired Clean the motor
As a matter of principle, the instructions in the project planning and commissioning manuals must be
followed in case of failures and errors. Contact the manufacturer, if necessary.
13
Technical data
13.1
Technical data
Type Standstill torque
- 100K
1)
Standstill cur-
rent - 100K
Rated current -
100K
Rated power -
100K
2)
Maximum speed
(electrical)
Mass
M
0 100K
Nm
I
0 100K
A
I
N 100K
A
P
N 100K
kW
n
max
1/min
m
mot
kg
MS2S03-B0BYN-____0-_N___-__ 0.92 1.63 1.06 0.37 9,000 1.4
MS2S03-B0BYN-____1-_N___-__ 0.92 1.63 1.06 0.37 9,000 1.8
MS2S03-C0BYN-____0-_N___-__ 1.55 2.75 1.56 0.45 9,000 1.9
MS2S03-C0BYN-____1-_N___-__ 1.55 2.75 1.56 0.45 9,000 2.3
MS2S04-B0BTN-____0-_N___-__ 2.10 2.72 1.58 0.58 6,000 2.7
MS2S04-B0BTN-____1-_N___-__ 2.10 2.72 1.58 0.58 6,000 3.4
MS2S04-C0BTN-____0-_N___-__ 3.50 3.9 2.09 0.72 6,000 3.7
MS2S04-C0BTN-____1-_N___-__ 3.50 3.9 2.09 0.72 6,000 4.4
MS2S05-B0BTN-____0-_N___-__ 4.45 5.5 3.19 1.37 6,000 4.0
MS2S05-B0BTN-____1-_N___-__ 4.45 5.5 3.19 1.37 6,000 5.1
MS2S05-C0BTN-____0-_N___-__ 7.15 8.3 4.69 1.59 6,000 5.9
MS2S05-C0BTN-____1-_N___-__ 7.15 8.3 4.69 1.59 6,000 7.0
1) 2) see table Tolerance
specifications of the motor data
For more technical data and characteristic curves please refer to the project planning manual.
