VII. Component Testing/Test Procedures
Models
Buttons to Enter Test Program
SHU/SHI430x, SHU431x
Power Scrub Plus + Regular Wash
SHU33/DLX
Power Scrub Plus + Rinse & Hold
SHU43C, SL34A, SHU432x
Regular Wash + Rinse & Hold
SHU53/66C/68, SHI66A/68
Scrub Wash + Delicate/Econo
SHU53A, SHX/SHY56, SL95A
Regular Wash + Quick Wash
SHU88
Power Scrub Plus + Quick Wash
SHU990x, SHV43/48
Power Scrub Plus + Regular Wash
SHU991x (thru UC/11)
Power Scrub Plus + Quick Wash
SHU991x (UC/12), SHU992x
Power Scrub Plus + Delicate/Econo
SHU995x
Regular Wash + Delicate Wash
SHV46C, SL84A, SHX43E/ 46A-B
Power Scrub + Delicate/Econo
SHV66A, SHY66A
Scrub Wash + Delicate/Econo
SHV68
Scrub Wash + Regular Wash
SHV99, SHX99, SHY99
(2) left buttons (see below)
SHX33A
Power Scrub + Rinse & Hold
GI976/966, GM276
Intensive + Delicate
DW44
Heavy Wash + Light Wash
Using test programs for various models (UC/06 - UC/14)
To enter test programs, hold down buttons above (2nd & 4th from left), then
turn dishwasher on by pushing on/off button. Push buttons above a 2nd
time to start test program. Allow program to finish to see fault codes. Turn
dishwasher off to exit test program.
To enter SHV/X/Y99 test program, open door, hold down 2 left buttons &
turn dishwasher on by pushing on/off button. Press “+” button repeatedly
until "S-3-" shows on display, then push start button to check faults on last
8 washes. Close door to begin test program. Allow program to finish to
see fault codes. Push “-” button to skip test steps. Turn dishwasher off to
exit test program. Choose “S-6-” to clear fault codes.
VII. Component Testing/Test Procedures
Using Test Programs
Using Test Programs
HINT: Dishwasher test programs heat water to 150ºF, so test
programs will generally run > 20 minutes for incoming water
temperatures ~ 120ºF.
HINT: Open door to select test
program for fully-integrated models,
then close door to run program.
NOTE: Flow through
heaters heat water ~
2ºF / minute.
