Operating Temperatures and Pressures | 61SM Series Heat Pump
6 720 220 406 (2015/02)Revised 02-15
COOLING HEATING
Model Entering
Water
Temp. F
Water
Flow
GPM
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Water
Temp
Rise °F
Air
Temp
Drop °F
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Water
Temp
Drop °F
Air
Temp
Rise °F
SM070
Part
Load
30°
9.0 72-92 267-307 4-8 17-21
18.0 68-88 261-301 1-5 18-22
40°
9.0 91-111 283-323 5-9 20-24
18.0 87-107 277-317 2-6 21-25
50°
9.0 130-150 173-213 14-18 29-33 109-129 299-339 6-10 23-27
18.0 125-145 159-199 6-10 31-35 105-125 293-333 3-7 25-29
60°
9.0 132-152 213-253 13-17 28-32 128-148 315-355 8-12 26-30
18.0 127-147 197-237 6-10 29-33 124-144 309-349 3-7 27-31
70°
9.0 134-154 253-293 13-17 26-30 147-167 331-371 9-13 30-34
18.0 129-149 235-275 6-10 28-32 143-163 325-365 4-8 32-36
80°
9.0 137-157 294-334 12-16 25-29 165-185 347-387 11-15 34-38
18.0 132-152 273-313 5-9 26-30 161-181 341-381 5-9 36-40
90°
9.0 139-159 334-374 12-16 23-27
18.0 134-154 311-351 5-9 24-28
100° 9.0 142-162 374-414 11-15 22-26
18.0 137-157 349-389 5-9 23-27
SM070
Full
Load
30°
9.0 69-89 289-329 6-10 18-22
18.0 65-85 283-323 2-6 20-24
40°
9.0 85-105 307-347 7-11 21-25
18.0 81-101 301-341 3-7 23-27
50°
9.0 123-143 185-225 18-22 29-33 101-121 325-365 9-13 24-28
18.0 118-138 171-211 9-13 31-35 97-117 319-359 4-8 26-30
60°
9.0 125-145 226-266 18-22 28-32 118-138 342-382 11-15 27-31
18.0 120-140 210-250 8-12 29-33 114-134 336-376 5-9 29-33
70°
9.0 127-147 268-308 17-21 27-31 134-154 360-400 12-16 31-35
18.0 122-142 250-290 8-12 28-32 130-150 354-394 6-10 34-38
80°
9.0 130-150 311-351 17-21 25-29 151-171 378-418 14-18 34-38
18.0 125-145 290-330 8-12 27-31 147-167 372-412 7-11 38-42
90°
9.0 132-152 353-393 16-20 24-28
18.0 127-147 330-370 7-11 25-29
100° 9.0 134-154 394-434 16-20 23-27
18.0 129-149 369-409 7-11 24-28
This chart shows approximate temperatures and pressures for a unit in good repair. The values shown are meant
as a guide only and should not be used to estimate system charge. This chat assumes rated air flow and 80º d.b./
67º w.b. entering air temperature in cooling, 70º d.b. entering air temperature in heating. Heating data at entering
fluid temperatures below 50º assumes the use of antifreeze. As a result of continuing research and development,
specifications are subject to change without notice.
