Bosch Solution-16 safecom - Fault Analysis

Day Alarm – Toggle On/Off (V1.10)
1. Enter the Master Code followed by 7 and the
# key [eg. 2580 + 7 + #].
Day Alarm – Toggle On/Off (V1.20+)
1.
Press and hold the 4 key until two beeps are
heard.
STAY Mode 2 Zones - Program
1. Enter the Master Code followed by 8 and the
# key [eg. 2580 + 8 + #].
2. Enter the Zone Number that you want the
system to automatically isolate followed by the
* key.
3.
Repeat if more than one zone to be
automatically isolated when armed in STAY
Mode 2.
4. Press the # key to terminate.
Fault Analysis
1.
Press and hold the 5 key until two beeps are
heard.
2.
Zone Indicators will display FAULT condition
(see table below).
3.
Press # key to terminate.
Zone LED FAULT Condition
1
Battery Low
2
Date / Time Reset
3
Sensor Watch Fail
4
Horn Speaker Fail
5
Telephone Line Fail
6 EPROM Fail
7
Zone 16 In Alarm (Partitioning)
8 Communication Fail
Modem Call (Alarm Link)
1. Press and hold the 6 key until two beeps are
heard.
Latching Outputs (Reset)
1. Press and hold the 7 key until two beeps are
heard.
Codepad ID / Buzzer Tone
1. Press and hold the 8 key until the desired
buzzer tone has been reached.
If the system has been partitioned, the
codepad will display a number to identify
which area the codepad belongs to (see table
below).
2.
Press the # key to terminate.
Zone LED Codepad Assignment
1
Area 1
2 Area 2
3
Area 3
4
Area 4
7
Master Partitioned Codepad
Test Report
1. Press and hold the 9 key until two beeps are
heard.
Speaker Test
1. Press and hold the 1 key until two beeps are
heard. The horn speaker will sound for two
seconds.
Bell Test
1.
Press and hold the 2 key until two beeps are
heard. The piezo will sound for two seconds.
Strobe Test (Toggle On/Off)
1.
Press and hold the 3 key until three beeps are
heard to turn the strobe on.
2.
Press and hold the 3 key until two beeps are
heard to turn the strobe off.
Solution-16/Solution-16
Safecom
Quick Reference Guide
7
Bosch Security Systems Pty Limited
