12 | Refrigerant Lines
Subject to change without prior notice
Charge Adjustments (oz) for SM Split CS when Paired with BOSCH BMAC
Table 5 Charge Adjustments (oz) for SM Split CS when Paired with BOSCH BMAC
TXV Adjustments for SM Split CS when Paired with BOSCH BVA2.0
Table 6 TXV Adjustments for SM Split CS when Paired with BOSCH BVA2.0
CS MODEL
Cased/Uncased Coil Model
BMAC2430BNTD BMAC3036BNTD BMAC4248CNTF BMAC4860CNTF
SM024-1CSC
-10
SM024-1CSN
-11
SM036-1CSC
-4
SM036-1CSN
-4
SM048-1CSC
12
SM048-1CSN
10
SM060-1CSC
10
SM060-1CSN
10
CS MODEL
Air Handler Model
BVA-24WN1-M20 BVA-36WN1-M20 BVA-48WN1-M20 BVA-60WN1-M20
SM024-1CSC
None
SM024-1CSN
None
SM036-1CSC
SM: 1 Turn Closed
BVA: None
SM036-1CSN
SM: 1 Turn Closed
BVA: None
SM048-1CSC
SM: 1 Turn Closed
BVA: None
SM048-1CSN
SM: 1 Turn Closed
BVA: None
SM060-1CSC
SM: 1 Turn Closed
BVA: None
SM060-1CSN
SM: 1 Turn Closed
BVA: None
