Refrigerant Lines | 13SM Split CS Series Heat Pump
8733825873 (2020/05)SM Split CS Series Heat Pump
Subject to change without prior notice
TXV Adjustments for SM Split CS when Paired with BOSCH BMAC
Table 7 TXV Adjustments for SM Split CS when Paired with BOSCH BMAC
BVA2.0 Rated Airflow Adjustment when Paired with SM Split CS Models
Table 8 BVA2.0 Rated Airflow Adjustment when Paired with SM Split CS Models
CS MODEL
Cased/Uncased Coil Model
BMAC2430BNTD BMAC3036BNTD BMAC4248CNTF BMAC4860CNTF
SM024-1CSC
None
SM024-1CSN
None
SM036-1CSC
SM: 1 Turn Closed
BMAC: None
SM036-1CSN
SM: 1 None
BMAC: None
SM048-1CSC
SM: 1 Turn Closed
BMAC: None
SM048-1CSN
SM: 1 Turn Closed
BMAC: None
SM060-1CSC
SM: None
BMAC: 1 Turn Closed
SM060-1CSN
SM: None
BMAC: 1 Turn Closed
CS Model Air Handler Full-Load-Rated
Airflow
Part-Load-Rated
Airflow
Blower Setting
(High/Low)
SM024-1CS BVA24 900 600 5/3
SM036-1CS BVA36 1200 900 5/3
SM048-1CS BVA48 1600 1200 4/2
SM060-1CS BVA60 1700 1400 5/3
